Description
Main features
- Horizontal double wall construction
- Robust 4mm and 5mm thick 304L stainless steel inner tank with manhole access
- Outer wall made of 4mm and 5mm thick S275 mild steel. 110% tank capacity
- Wide double cradle base with angled drop
- Suitable lifting rings to lift, move and install the empty tank
- Open front design for easy access to fuel dispenser, with rain screen and galvanised pump support
- Additional cabinet with vented side entry door giving access to filters, reel and offset fill line.
- Side cabinet with roller shutter and power supply
- Fill point
- 2″ stainless steel with self-locking pressure valve for Jet A1 / Avgas
- Hydrostatic tank contents gauge
- 1″ stainless steel suction line with anti-syphon
- Shot blasted and painted in polyurethane paint (white standard)
- Standard specification
- Pumptronics C Series fuel dispensing unit with stainless steel body and digital display
- Flow rate of 80 to 90 litres / min *, motor ATEX Exd IIB T4 230V 50Hz. MID approved
- Stainless steel pump internals with gas separator
- Dual Facet VF-22SB filter vessel tested to EI I 1581 (5th edition). Differential pressure gauge and water drain
- Absorbent filter to EI / API 1583 (4th edition) (particle and water blocking, 0.5 micron)
- Coalescing cartridge API 1581 5th edition
- Hydraulic hose reel with aviation hose certified to EN 1361, API 1529 C
- ZVF25 manual shut-off gun with removable fine mesh strainer, complete with ground wire and dust cap. (Automatic gun optional)
- 30 m equipotential bonding
- Fuel sampling, inspection and recovery system for water drainage with 4 L closed circuit sampler
- EX50 230 V sampling and return pump (equipped with tank, Facet VF-22SB return filter with coalescing filter element)
Available options:
- 304L stainless steel floating suction (mandatory for some oil companies: TOTAL, K9 aviation, WARTER REPSOL …)
- Stainless steel centrifugal tank refuelling pump, 230V ATEX (required for delivery by gravity truck)
- Tank inlet filtration, 2 micron particle element EI 1590 qualified,
- Access platform for 10,000 L to 15,000 L tank
- Galvanised non-slip staircase and manhole access platform for easy and safe access
- Exterior floodlights and mounting posts, with light controller
- Grounding wire at the gun
